Semi-Automatic Ampoule Visual Inspection Machine For Pharmaceutical Quality Control In Nigeria
Ampoule Visual Inspection Machine Details
Revolutionize Ampoule Quality Control in Nigeria
Technogen Enterprise, is a globally trusted manufacturer, supplier, and exporter of high-precision Ampoule Visual Inspection Machines. Our semi-automatic inspection machines are designed to enhance the quality assessment of ampoules in pharmaceutical and injectable plants, combining reliability, efficiency, and cutting-edge technology.
The TGAIM-60 Ampoule Visual Inspection Machine is specially engineered for the accurate detection of foreign particles such as glass shards, dirt, filter residues, black particles, and cracks within ampoules. It accommodates vials up to 10 ml, with optional change parts for varied sizes, enabling pharmaceutical manufacturers in Nigeria to maintain the highest standards of product safety and compliance.
Why Choose Technogen Enterprise Ampoule Visual Inspection Machines?
Our inspection machines are built to maximize efficiency, reduce manual intervention, and ensure precise quality control.
Salient Features:
High Hygiene & Durability: All liquid-contact parts are made from SS 304, ensuring hygienic operations and long-lasting performance.
Efficient Ampoule Loading & Unloading: Tray-based system allows for convenient loading/unloading, streamlining inspection workflow.
Independent Variable Frequency Drives: Separate VFDs for the main machinery and ampoule spinning assembly provide precise control over rotation speed.
Advanced Reflex Photoelectric Sensor: Mounted in an aluminum star wheel, this sensor ensures accurate separation of ampoules during inspection.
Multiple Ampoule Spinners: Six high-speed spinners generate a liquid vortex for enhanced particle detection.
Magnified View: Observe six ampoules simultaneously with backlit illumination for real-time clarity.
Versatile Magnification: 1.75X overall magnification, with up to 3X on specific areas for detailed analysis.
Powerful Magnifying Lamps: Two 18W lamps, each delivering 1800 Lumens, ensure proper illumination.
Convenient Ejection Switch: Simplifies the rejection process for defective ampoules.
Repeat Cycle Arrangement: Allows optimization of production cycles for consistent inspection.
Comprehensive Production Monitoring: Dual inbuilt counters track total production and rejection counts, ensuring accurate monitoring.
Technogen Enterprise ensures that your quality control processes are efficient, precise, and compliant with international standards, enhancing reliability for pharmaceutical production in Nigeria.
Technical Specifications
| Specification | Details |
|---|---|
| Machine Name | Ampoule Visual Inspection Machine |
| Model | TGAIM-60 |
| Automation Grade | Semi-Automatic |
| Application | Detect foreign bodies: glass shards, dirt, filter residues, black particles, cracks |
| Brand | Technogen Enterprise |
| Direction of Movement | Left to Right |
| Machine Speed | 50–60 Ampoules per minute (depends on operator skill) |
| Speed Variation | Via Variable Frequency Drive |
| External Finish | Premium Stainless Steel Matt Finish |
| Ampoule Diameter Range | 10–15 mm |
| Number of Spinning Assemblies | 6 |
| Ampoule Height | 55–125 mm |
| Ampoule Loading | Tray |
| Working Height (Sitting Position) | 1200 mm to eye level |
| Electrical Connection | 230 V, 1 Ph, 50 Hz, proper earthing |
| Control Panel | SS 304 bottom pendant type, machine-mounted |
| Counters | 2 (Total production & Rejection count) |
| Power Consumption | 1.5 KW |
| Compressed Air | 2 KG/cm² |
| Overall Dimensions (L×W×H mm) | 1600 × 1050 × 1600 |
| Net Weight | 250 KG |
| Gross Weight | 475 KG |
| Warranty | 1 Year from dispatch |
| Country of Origin | India |
Material of Construction
| Part | Material |
|---|---|
| Main Body | AISI 304 |
| Top Plate | Mild Steel with AISI 304 cladding |
| Doors | AISI 304 |
| Infeed / Input Tray | AISI 304 |
| Outfeed Tray | AISI 304 |
| CAM | CI Casting |
| Star Wheel | Aluminum |
| Hopper | AISI 304 |
| Ampoule Holder | Brass & Aluminum |
| Output & Rejection Hopper | AISI 304 |
| Gears | Mild Steel |
| Chain Sprockets | Mild Steel |
| Spinning Gear | Nylon |
| Spinning Head | Mild Steel Plate with AISI 304 cladding |
| Rack for Ampoule Movement | Aluminum |
| Rack for Ampoule Holding | AISI 304 |
| Hopper Gear Box | Aluminum |
| Electrical Panel Box | AISI 304 |
| Operating Panel | AISI 304 |
| Shafts | Mild Steel |
| Gear for Hopper Gear Box | Mild Steel |
| Spinning Roller | Aluminum |
Trade Details
Minimum Order Quantity: 1 Machine
Production Capacity: 4 Machines per Month
Product Ordering Code: TGAIM-60
Delivery Time: 4–5 Weeks
Packaging: ISBM-15 compliant, sea-worthy
Nearest Seaport: Mudra, Gujarat, India
Payment Mode: International T/T or L/C
Elevate Your Pharmaceutical Quality Control
Technogen Enterprise empowers pharmaceutical companies in Nigeria to achieve superior quality control standards with our semi-automatic Ampoule Visual Inspection Machine. Designed for accuracy, efficiency, and compliance with CGMP standards, this machine reduces human error while delivering precise inspection results.
Contact Technogen Enterprise today to discuss your requirements and experience the reliability, innovation, and high performance of our Ampoule Visual Inspection Machines.
