Automatic Servo Driven Gear Pump Bottle Liquid Filling Machine In Nigeria
Automatic Servo Driven Gear Pump Type Bottle Liquid Filling Machine Details
Introduction to Automatic Servo Driven Gear Pump Bottle Liquid Filling Machine
Technogen Enterprise is a leading manufacturer, supplier, and exporter of state-of-the-art packaging solutions, proudly delivering machines designed for precision, hygiene, and performance. Among our advanced product line, the Automatic Servo Driven Gear Pump Type Bottle Liquid Filling Machine has become a popular choice across Nigeria’s dynamic industrial hubs, including Lagos, Abuja, Kano, Port Harcourt, Ibadan, Onitsha, and Aba.
This high-quality filling machine is engineered to handle a wide variety of liquids — from edible oils, beverages, honey, syrups, sauces, and cosmetics, to chemicals and pharmaceuticals. Built with servo-driven gear pump technology, the machine ensures highly accurate metering and filling, making it a versatile solution for industries that require both speed and precision.
Why Nigerian Businesses Need Servo Driven Gear Pump Liquid Filling Machines
Nigeria’s industrial sector is evolving rapidly, with rising demand for modern packaging solutions. Whether it’s food and beverage processors in Lagos, pharmaceutical manufacturers in Abuja, or oil bottling companies in Port Harcourt, efficiency and accuracy are key.
The Technogen Servo Driven Gear Pump Liquid Filler offers the following advantages for Nigerian manufacturers:
Flexible Filling Options: Suitable for conductive and non-conductive liquids, including foamy, viscous, or free-flowing products.
High Accuracy: ±2% filling precision ensures consistency and reduces wastage.
Scalable Design: Available in 4, 6, or 8-head configurations to match production needs.
Hygiene Standards: All liquid-contact parts are made from AISI 316L stainless steel, PTFE, or silicone, meeting international food and pharma standards.
Efficiency: Servo-driven gear pumps and automated controls reduce labor dependency and improve line performance.
Durability: Rugged stainless steel body ensures long life even in demanding factory environments.
Key Features of Automatic Servo Driven Gear Pump Bottle Liquid Filling Machine
The machine comes equipped with cutting-edge features that enhance productivity while ensuring operational simplicity.
Salient Features:
CGMP-compliant model suitable for regulated industries like pharma and food.
Modular and rugged construction for easy expansion and long-term use.
Machine body and doors fabricated with stainless steel for strength and hygiene.
All contact parts crafted from AISI 316L stainless steel, PTFE, or silicone.
No Bottle – No Fill system prevents wastage of valuable liquids.
Independent servo motor-driven gear pump for each filling head.
Tool-less adjustable conveyor guide rails to handle different bottle sizes.
Dive-in nozzles minimize foaming when filling liquids like shampoo or detergent.
Fill volume set directly from HMI (Human Machine Interface).
Inbuilt PLC and touch screen HMI for streamlined operations.
Recipe-based operations with elite fill test facility for new products.
Fill range from 10 ml to 1000 ml without changeover parts.
Filling accuracy better than ±2%.
Pneumatic bottle stoppers ensure precise positioning during filling.
Variable frequency drive (VFD) allows speed adjustment.
High-precision pumps ensure drip-proof filling performance.
Servo-driven centrifugal pumps enhance operational efficiency.
Ergonomically designed control panel for operator convenience.
Designed for easy cleaning and quick changeover.
Technical Specifications of Servo Driven Gear Pump Bottle Liquid Filler
| Specification | TGLF-50SG | TGLF-80SG | TGLF-100SG |
|---|---|---|---|
| Number of Filling Heads | 4 Head | 6 Head | 8 Head |
| Output (100 ml fill) | 40–50 BPM | 80–90 BPM | 100–110 BPM |
| Power Consumption | 1.5 KW | 2 KW | 2.5 KW |
| Operating Direction | Left to Right | Left to Right | Left to Right |
| Filling Technology | Servo Motor Based Metering | Servo Motor Based Metering | Servo Motor Based Metering |
| Bottle Holding | Star wheel or Pneumatic stopper | Star wheel or Pneumatic stopper | Star wheel or Pneumatic stopper |
| Filling Accuracy | ±2% (depending on liquid properties) | ±2% | ±2% |
| Filling Range | 10 ml to 1000 ml | 10 ml to 1000 ml | 10 ml to 1000 ml |
| Bottle Diameter | 16 mm – 100 mm | 16 mm – 100 mm | 16 mm – 100 mm |
| Bottle Height | Up to 200 mm | Up to 200 mm | Up to 200 mm |
| Power Requirement | 440 V, 3 Phase, 50 Hz, 4 Wire System | 440 V, 3 Phase, 50 Hz, 4 Wire System | 440 V, 3 Phase, 50 Hz, 4 Wire System |
Add-On Features for Customization
To cater to diverse industrial needs in Nigeria, Technogen provides optional add-ons for the liquid filling machine:
Toughened Glass / Polycarbonate / Acrylic Safety Cabinet with door interlock.
Turn Table for seamless product handling.
21 CFR Part-11 Compliance for pharma-grade traceability and audit requirements.
Applications Across Nigerian Industries
The Automatic Servo Driven Gear Pump Type Bottle Liquid Filling Machine is suitable for a wide range of applications:
Food & Beverage (Lagos, Ibadan, Kano):
Juices, syrups, sauces, cooking oil, water, dairy products.
Pharmaceuticals (Abuja, Lagos, Onitsha):
Cough syrups, tonics, suspensions, oral liquids.
Chemicals (Port Harcourt, Aba):
Detergents, cleaning liquids, agrochemicals.
Cosmetics & Personal Care (Lagos, Abuja):
Shampoos, lotions, hand sanitizers, oils.
Honey & Specialty Products (Kaduna, Ibadan):
Honey jars, nutritional syrups, viscous health drinks.
Benefits for Nigerian Manufacturers
Adopting the TGLF-50SG / TGLF-80SG / TGLF-100SG models comes with multiple advantages:
Boosted Efficiency: Multi-head configurations allow higher output.
Accuracy in Filling: Servo-driven gear pump ensures precise metering.
Hygiene Standards: Meets CGMP requirements, suitable for pharma and food.
Cost Reduction: Reduces wastage with “No Bottle – No Fill” system.
Scalable: From 4 to 8 heads, expandable with production growth.
Versatility: Handles foamy, viscous, or free-flowing liquids seamlessly.
Operator-Friendly: Recipe-based operations and touch-screen interface.
Compact & Durable: Stainless steel construction ensures longevity.
Why Partner with Technogen Enterprise in Nigeria?
Technogen has emerged as a trusted partner for Nigerian industries due to our dedication to quality, innovation, and customer support.
Presence across Nigeria: Supporting industries in Lagos, Abuja, Kano, Port Harcourt, Ibadan, Onitsha, and Aba.
Affordable Pricing: Delivering world-class machines at competitive costs.
After-Sales Service: Installation, operator training, maintenance support.
Customization Options: Machines tailored to unique production requirements.
Compliance Assurance: All machines built to global CGMP standards.
Final Note
For Nigerian businesses looking to achieve precision, hygiene, and efficiency in liquid packaging, the Technogen Automatic Servo Driven Gear Pump Type Bottle Liquid Filling Machine is the ultimate solution. With models ranging from 4-head to 8-head configurations, it delivers scalable performance for industries across food, beverage, pharmaceuticals, cosmetics, chemicals, and specialty products.
